PCB Capabilities



Materials Standard Advanced
FR4 (130‐180 Tg by DSC) Y Y
Halogen Free Y Y
BT Epoxy Y Y
Getek Y Y
Isola 370HR 406 408 IS410 IS 420 IS620 Y Y
Nelco 4000 Y Y
Rogers 4000 Y Y
PTFE Y Y
Dupont Pyralux N Y
Aluminum Core Y Y
Surface Finishes
ENIG Y Y
Flash Gold Y Y
Electrolytic Nickel/Hard Gold Y Y
HASL Y Y
Lead Free HASL Y Y
Immersion Ag Y Y
Standard Features Standard Advanced
Maximum layer count 20 36
Maximum Panel Size 21″x24″ 24″x30″
Outer Layer Trace/Spacing (1/3 oz) 0.0035″/0.0035″[90μm/90μm] 0.0025″/0.003″[64μm/76μm]
Inner Layer Trace/Spacing (H oz) 0.003″/0.003″ [76μm/76μm] 0.002″/0.0025″ [50μm/64μm]
Maximum PCB thickness 0.125″[3.2mm] 0.177″[4.5mm]
Minimum PCB thickness 0.008″[0.20mm] 0.004″[0.10mm]
Minimum mechancial drill size 0.008″[0.20mm] 0.004″[0.10mm]
Maximum PCB aspect ration 10:01 12:01
Maximum copper weight 5 oz [178μm] 6 oz [214μm]
Minimum copper weight 1/3 oz [12μm] 1/4 oz [9μm]
Minimum core thickness 0.002″[50μm] 0.0015″[38μm]
Minimum dielectric thickness 0.0025″[64μm] 0.0015″[38μm]
Minimum Pad Size over Drill 0.018″[0.46mm] 0.016″[0.4mm]
Solder Mask Registration +/‐ 0.002″[50μm] +/‐ 0.0015″[38μm]
Mimimum Solder Mask Dam 0.003″[76μm] 0.0025″[64μm]
Copper feature to PCB edge 0.015″[0.38mm] 0.010″[0.25mm]
Tolerance on overall dimensions +/‐ 0.004″[100μm] +/‐ 0.002″[50μm]
HDI Features
Immersion Tin Y Y
